Zoom range:
Gobos: 17
Light source: Philips 280W
Prism: A 8+16-facet,a 8+16+24 facet
Color: 14
Consult Now
DetailSpecificationApplication

Light Source

Philips 280W lamp

31*0.5W RGB LED

Life expectancy:5000hours

*It may vary depending on various factors, as type of use and environment

Optical System

Advanced optical design to ensure precise gobos colors

Beam angle:2°C

Front lens diameter: 152mm

CONTROL and CONNECTIONS

16 DMX channels

Protocols:DMX512

Control Protocol: DMX 512 , Sound control , Auto , Master-slave

DMX connectors:   3 pin XLR IN/THRU

Display :LCD display

DYNAMIC EFFECTS

One color wheel with 14 Colors

One gobo wheel with 17 Gobos

Rotating one 8+16-facet Prism one 8+16+24-facet Prism spin CCW and CW

Movement: PAN range 540° - TILT range 270°

Pan/Tilt resolution : 16bit

Automatic Pan/Tilt position correction

Electrical and Connectors

Input Voltage Range: 100-240V 50/60Hz

Power consumption : 320 W

Power In/Out : Power Connector In/Out

Date In/Out: 3-pin XRL

Fixture Specification

Fixture Dimensions

Width:284mm

Depth:234mm

Height:445mm

Wight: 10.5kg

Carton Case Dimensions (1in1)

Width:510mm

Depth:350mm

Height:370mm

Wight:12kg

Flight case Dimensions (2pcs inside)

570mm*450mm*550mm

G. W:39kgs

Work Environment

Maximum ambient temperature:40 °C

Minimum operating temperature:0°C

Protection rating IP20

Installation

Available in horizontal or vertical mounting

Universal working position

2x fixed foldable clamps for 50mm truss

Optional safety chain

Accessories

User Manual (included)

Power Cable (included)

Factory certificate and warranty card (included)

2x fixed foldable clamps for 50mm truss (optional)

Raincover:3033001749 (optional)

Safety Rope: 2060001603-A(SW-05) (optional)

Signal Line:1.5mter 3-pin signal line (optional)
